Fsk17067_wf.png ‎(598 × 394 pixels, file size: 431 KB, MIME type: image/png)

Waterfall of the 17067bps GFSK signal. Top row is most recent. Bandwidth 26 kHzKiloHertz (kHz) 10^3 Hz, 42 msmilliseconds (.001 of a second)/row.

File history

Click on a date/time to view the file as it appeared at that time.

Date/TimeDimensionsUserComment
current11:23, 6 March 2025598 × 394 (431 KB)Kj6psg (Talk | contribs)Waterfall of the 17067bps GFSK signal. Top row is most recent. Bandwidth 26 kHz, 42 ms/row.
